Trailing Cable Power Supply System
* Remote control operation allows operators to manage gate opening and closing via wireless devices for precise water flow regulation
* Automated control system adjusts gate positions based on preset water levels, flow rates, or other data parameters, enabling intelligent water resource management
* IoT-enabled remote monitoring allows users to track gate status and hydrological data in real time via network connections
* On-site installation support and technical guidance supplied
Trailing Cable Power Supply System for Center Pivot Irrigation
Anhui Showy Agricultural Irrigation Technology Co., Ltd. delivers a robust Trailing Cable Power Supply System engineered specifically for center pivot and linear irrigation equipment operating across expansive agricultural fields. Our system incorporates precision gearmotors rated at 25.5:1 (1.5 hp) and 40:1 (0.75 hp) combinations, together with armored wire that complies with UL standards. We promise high-durability cable management that can meet main pipeline standards from 5" (127mm) to 8-5/8" (219mm) across span lengths up to 66.5 meters, supported by our 34,000-square-meter production workshop with an annual capacity of 1,800 irrigation systems. In harsh field situations, the hot-dip galvanized construction guaranties more than 20 years of operating life.
How the System Powers Large-Scale Irrigation
The Trailing Cable Power Supply System maintains continuous electrical delivery to moving pivot structures as they traverse circular or linear irrigation paths. Cable specifications include heavy-duty armored construction that protects conductors from soil abrasion, moisture ingress, and UV degradation during seasonal operation.
With configurable overhang lengths up to 25 meters, our system supports variable span combinations ranging from 37.5 to 66.5 meters. The cable management design ensures dependable power transfer to drive motors, control panels, and end-gun sprinkler assemblies by preventing excessive bending stress during pivot rotation.
Electrical performance metrics can be remotely monitored thru integration with SAIT Smart Control Systems. IoT-enabled interfaces that communicate over up to 5 km using LoRa or GPRS protocols allow you to monitor voltage stability, identify cable problems early, and plan maintenance.
Technical Specifications
| Component | Specification |
|---|---|
| Cable Type | Armored Cable (UL Listed) |
| Gearmotor Options | 25.5:1 (1.5hp); 40:1 (0.75hp) |
| Wheel Gearbox | 50:1, 52:1 |
| Main Pipeline Sizes | 5"(127mm), 6-5/8"(168mm), 8-5/8"(219mm) |
| Span Length Range | 37.5m - 66.5m |
| Overhang Length Options | 2.7m - 25m (Customizable) |
| Span Height | 2.1m - 4.5m |
| Wheel Sizes | 11.2-24, 14.8-24, 16.9-24 (Tube/Tubeless) |
| Truss Rod Diameter | 20mm, 22mm |
| Outlet Spacing | 1.9m, 2.9m (Customizable) |
Performance Advantages in Field Conditions
Your irrigation operations demand uninterrupted power delivery across hundreds of hectares. Our system achieves over 70% water savings compared to flood irrigation while maintaining electrical reliability throughout irrigation cycles covering 4 to 200 hectares per operation.
The hot-dip galvanized cable carriers feature minimum 80μm zinc coating thickness, providing exceptional corrosion resistance in high-humidity environments. This treatment extends functional lifespan beyond 20 years even under continuous exposure to fertilizer residues and irrigation water.
Automated control integration allows the system to support Variable Rate Irrigation (VRI) through precision electrical signal transmission. You can implement zone-based irrigation schedules and real-time flow adjustments coordinated with big data models for optimal resource allocation.
Smart Control Integration
Modern agricultural operations require intelligent monitoring capabilities. The Trailing Cable Power Supply System seamlessly connects with wireless control modules operating on 9-24V DC power with battery capacities ranging from 9Ah to 40Ah depending on system configuration.
Solar panel integration options (20W-90W) provide supplementary charging for remote field installations where grid access remains limited. Communication protocols support both GPRS and LoRa transmission with effective ranges extending 1-5 km for centralized farm management.
Remote operators can monitor cable tension, electrical load distribution, and system diagnostics through cloud-based platforms. Scheduled maintenance alerts trigger automatically based on accumulated operating hours and environmental exposure metrics.
Installation and Field Support
Our engineering team provides comprehensive on-site installation guidance to ensure proper cable routing, tension adjustment, and electrical termination. Technical support includes span alignment verification, gearbox synchronization testing, and control system commissioning.
Cable management hardware installs directly onto the pivot structure's truss assembly using reinforced mounting brackets compatible with 20mm and 22mm truss rod configurations. The modular design accommodates field modifications and span extensions without complete system replacement.
We supply detailed wiring diagrams, torque specifications, and electrical safety protocols tailored to your specific pivot configuration. Post-installation training covers routine inspection procedures, tension adjustment techniques, and troubleshooting protocols for common field conditions.
Frequently Asked Questions
Q: What maintenance does the cable system require?
A: Perform monthly visual inspections for sheath damage or unusual wear patterns. Check cable tension quarterly and inspect electrical connections semi-annually. Our hot-dip galvanized components require minimal maintenance beyond routine cleaning.
Q: Can the system handle variable terrain?
A: Yes, our span height options (2.1m to 4.5m) and wheel size configurations (11.2-24 through 16.9-24) accommodate rolling terrain and obstacle clearance requirements while maintaining proper cable management geometry.
Q: How does the system perform during high-speed operation?
A: The gearmotor and wheel gearbox combinations (25.5:1 to 52:1 ratios) maintain consistent rotation speed. Our automatic brake system adjusts force dynamically to prevent cable whipping during acceleration and deceleration phases across the entire irrigation field.
Q: Is the cable compatible with VRI technology?
A: Absolutely. The UL-listed armored cable transmits both power and control signals required for precision VRI applications integrated with SAIT Smart Control Systems and third-party agricultural data platforms.
Q: What quality standards does Showy meet?
A: As a National Intellectual Property Advantageous Enterprise with water-saving certification, we participate in drafting national irrigation equipment standards. Our manufacturing facility holds First Prize awards in Agricultural Machinery Science and Agricultural Water-Saving Technology.
Contact Our Irrigation Specialists
Upgrade your center pivot system with proven Trailing Cable Power Supply System cable management technology. Reach our technical team at kevin@showyirrigation.com for customized specifications and project consultation.
Get a tailored irrigation solution for your project — our engineering team is ready to support you from design to installation.
